Display System
- Display DeviceSXRD 0.61" x3
- Panel Resolution3,840 x 2,160
Light Output / Contrast
- Light Output2.700 lm
- Dynamic Contrast∞: 1
Light Source
Projection Lens
- TypePowered
- Zoom RatioApprox. x2.1
- Lens ShiftVertical +/- 85 %,
Horizontal +/- 36 %
- Throw Ratio1.35-2.84
- Picture Position5
Picture Processor
- Picture ProcessorXR Processor for projector
- ContrastXR Dynamic Tone Mapping
XR Deep Black
- ColorXR Triluminos Pro
- ClarityXR Clear Image
- MotionMotionflow
Accepted Digital Signals
- Accepted Digital Signals720x576/50p, 720x480/60p, 1280x720/50p, 1280x720/60p,
1920x1080/50i, 1920x1080/60i,
1920x1080/24p, 1920x1080/48p, 1920x1080/50p, 1920x1080/60p,
1920x1080/100p, 1920x1080/120p,
3840x2160/24p, 3840x2160/25p,
3840x2160/30p, 3840x2160/48p, 3840x2160/50p, 3840x2160/60p,
3840x2160/100p, 3840x2160/120p,
4096x2160/24p, 4096x2160/25p,
4096x2160/30p, 4096x2160/48p, 4096x2160/50p,
4096x2160/60p, 4096x2160/100p, 4096x2160/120p
- Accepted HDR FormatHDR10/HLG
Input Lag
- Input lag (4K 120P / 4K 60P/ 2K 120P)12ms / 21 ms / 12 ms *1
Inputs / Outputs
- HDMIx 2 (HDCP2.3)
- Features specified in HDMI2.14K120/ALLM
- REMOTEx1 (RS-232C, D-Sub 9-pin (Male))
- IR INx 1 (Mini jack)
- TRIGGERx 1 (Mini jack, DC 12 V, Max. 100 mA)
- LANx 1 (RJ45, 10BASE-T/100BASE-TX)
- USBx 1 (Type A, DC 5 V, Max. 500 mA) for Update
Other Functions
- Gamma CorrectionYes (HDR/SDR)
- Color CorrectionYes
- Digital Keystone CorrectionYes
- 3DNo
- Anamorphic CompatibilityYes
- OSD Languages18-languages (English, Dutch, French, Italian, German, Spanish, Portuguese, Turkish, Russian, Swedish, Norwegian, Japanese, Simplified Chinese, Traditional Chinese, Korean, Thai, Arabic, Polish)
Power Requirements
- Power RequirementsAC 100 V to 240 V, 50/60 Hz
Power Consumption
- Power Consumption380W
- Standby0.3 W (when “Remote Start” is set to “Off”)
- Networked Standby0.5 W (LAN)(When "Remote Start" is set to "On"). When a LAN terminal is not connected, it becomes a low power consumption mode (0.4W).
- Standby Mode / Networked Standby Mode ActivatedAfter about 10 Minutes
Ventilation
- Ventilation (In / Ex)Front/Back
Acoustic Noise
Dimensions w/o Protrusion
- Dimensions (W x H x D)Width: 460 mm, 18 1/8"
Height: 210mm, 8 9/32"
Depth: 517 mm, 20 11/32"
Mass
Temperature / Humidity
- Operating Temperature / Operating Humidity5℃ to 35℃ (41°F to 95°F)/20% to 80% (no condensation)
- Storage Temperature / Storage Humidity-10℃ to +60℃ (14°F to 140°F)/20% to 80% (no condensation)
Supplied Accessories
- Supplied AccessoriesRemote control (RM-PJ24) (x1)
Size AA (R6/LR6) batteries (x2)
Lens cap (x1)
AC power cord (x1)
Setup Guide (x1)
